Medium ACT Graph Analysis Practice Questions

Nearly 25% of the ACT Science section and a significant portion of the Math section require students to interpret visual data accurately. Success on these sections depends on your ability to quickly identify trends, determine relationships between variables, and extrapolate data points from various visual formats. This guide provides specialized Medium ACT Graph Analysis Practice Questions to help you bridge the gap between basic reading and complex data synthesis.

Concept Explanation

ACT Graph Analysis is the process of extracting, interpreting, and predicting information from visual data representations like line graphs, bar charts, scatterplots, and histograms. To excel in this area, you must understand three core components: the axes, the relationship, and the units. The independent variable is typically located on the x-axis, while the dependent variable is on the y-axis. You must be able to distinguish between direct relationships, where both variables increase together, and inverse relationships, where one increases as the other decreases. Additionally, paying close attention to the scale—whether it is linear or logarithmic—is essential for avoiding common traps. For a broader overview of these skills, you can explore our ACT Prep hub. Understanding these fundamentals allows you to tackle ACT multi-step data practice questions that often appear in the later stages of the test.

Solved Examples

Review these worked examples to understand the logic required for medium-level graph interpretation.

1. Example 1: Identifying Trends
   A line graph shows the solubility of Potassium Nitrate in water. At $20^\circ \text{C}$, the solubility is $30 \text{g}/100 \text{g}$ of water. At $50^\circ \text{C}$, it is $85 \text{g}/100 \text{g}$. What is the relationship between temperature and solubility?
   Solution:
   1. Identify the variables: Temperature (x) and Solubility (y).
   2. Observe the change: As temperature increases from $20^\circ \text{C}$ to $50^\circ \text{C}$, solubility increases from 30 to 85.
   3. Conclusion: There is a direct relationship between temperature and solubility.
2. Example 2: Interpolation
   A scatterplot shows a line of best fit for plant growth over 10 days. If the plant is $4 \text{cm}$ tall on Day 2 and $10 \text{cm}$ tall on Day 6, estimate the height on Day 4 assuming a linear growth rate.
   Solution:
   1. Calculate the rate of change: $\frac{10 - 4}{6 - 2} = \frac{6}{4} = 1.5 \text{cm/day}$.
   2. Apply the rate to the starting point: From Day 2 to Day 4 is 2 days.
   3. Calculation: $4 \text{cm} + (1.5 \times 2) = 7 \text{cm}$.
3. Example 3: Comparing Multiple Data Sets
   A bar chart compares the rainfall in three cities: City A (50 inches), City B (35 inches), and City C (65 inches). By what percentage does City C's rainfall exceed City B's?
   Solution:
   1. Find the difference: $65 - 35 = 30$.
   2. Set up the percentage increase formula: $\frac{ \text{Difference}}{ \text{Original Value}} \times 100$.
   3. Calculation: $\frac{30}{35} \approx 0.857$, which is approximately $85.7\%$.

Practice Questions

Test your skills with these Medium ACT Graph Analysis Practice Questions. Ensure you read the labels of every axis carefully before selecting an answer.

1. A graph displays the pressure of a gas vs. its volume at a constant temperature. If the pressure is $2 \text{ atm}$ at $10 \text{ L}$ and $4 \text{ atm}$ at $5 \text{ L}$, what type of relationship is shown?

2. In a study of enzyme activity, a bell-shaped curve shows peak activity at $\text{pH } 7$. If the activity at $\text{pH } 5$ is $20\%$ of the maximum, what is the likely activity at $\text{pH } 9$ based on a symmetrical distribution?

3. A line graph tracking the population of bacteria shows $100$ cells at $t=0$ and $800$ cells at $t=3$. If the growth is exponential, how many cells were present at $t=2$?

4. A histogram shows the test scores of a class. If the bin for 80-89 has a frequency of 12 and the total number of students is 40, what percentage of the class scored in the 80s?

5. A graph of velocity vs. time shows a straight line with a positive slope starting from the origin. What does the area under the curve represent from $t=0$ to $t=5$?

6. Referencing a dual-axis graph: The left y-axis shows temperature while the right y-axis shows CO2 concentration. If temperature increases whenever CO2 increases, what can be concluded about their correlation?

7. A pie chart shows energy sources: Solar ($15\%$), Wind ($25\%$), Hydro ($10\%$), and Fossil Fuels. What is the central angle in degrees for the Fossil Fuels sector?

8. A scatterplot shows a strong negative correlation between the age of a car and its resale value. If the value drops by $2,000 every year, and a new car costs $30,000, what is the predicted value after 7.5 years?

9. A cumulative frequency graph shows that the 50th percentile for height in a group is $165 \text{ cm}$. If 200 people were measured, how many people are shorter than $165 \text{ cm}$?

10. An experiment measures the cooling of a liquid. The temperature drops from $90^\circ \text{C}$ to $50^\circ \text{C}$ in 10 minutes. If the rate of cooling is constant, what will the temperature be after another 5 minutes?

Answers & Explanations

1. Inverse Relationship: As pressure doubled ($2 \rightarrow 4$), volume halved ($10 \rightarrow 5$). This is the definition of an inverse relationship (Boyle's Law).
2. 20%: Since the distribution is described as symmetrical and centered at $\text{pH } 7$, the values at equal distances from the center ($7-2=5$ and $7+2=9$) should be identical.
3. 400 cells: In exponential growth, the population doubles at regular intervals. Here, the population goes from 100 to 800 in 3 steps ($100 \rightarrow 200 \rightarrow 400 \rightarrow 800$). At $t=2$, the value is 400.
4. 30%: Calculate $\frac{12}{40} = 0.30$. Multiplying by 100 gives $30\%$. You can find more practice on data distributions in our ACT statistics interpretation practice questions.
5. Displacement: In a velocity-time graph, the area under the curve represents the total displacement (distance traveled in a specific direction).
6. Positive Correlation: Because the variables move in the same direction (both increase), they share a positive correlation. This is a common pattern in ACT scientific data practice questions.
7. 180 degrees: First, find the percentage for Fossil Fuels: $100 - (15 + 25 + 10) = 50\%$. A full circle is $360^\circ$, so $50\%$ of 360 is $180^\circ$.
8. $15,000: The total drop is $7.5 \times 2,000 = 15,000$. Subtract this from the initial price: $30,000 - 15,000 = 15,000$.
9. 100 people: The 50th percentile represents the median, or exactly half the population. $50\%$ of 200 is 100.
10. 30°C: The cooling rate is $\frac{90-50}{10} = 4^\circ \text{C/min}$. In 5 minutes, it will drop another $5 \times 4 = 20^\circ \text{C}$. $50 - 20 = 30^\circ \text{C}$.

1. If a line on a graph of Distance vs. Time is perfectly horizontal, what is the speed of the object?

• AConstant and fast
• BIncreasing
• CZero
• DDecreasing

Frequently Asked Questions

What is the most common type of graph on the ACT?

Line graphs and tables are the most frequent visual aids on the ACT, often used to show how a dependent variable changes over time or in response to an experimental factor. You will also frequently encounter bar graphs and scatterplots in the Science section.

How do I handle a graph with two different y-axes?

Always check which data series corresponds to which axis by looking at the legend or the labels. Usually, one line or set of bars will be tied to the left axis, and the other will be tied to the right axis.

What does it mean if a graph has a "break" in the axis?

A break (symbolized by two jagged lines) indicates that a large portion of the scale has been omitted to save space. This is usually done when the data points are very far from zero, and you must be careful not to misinterpret the relative height of the bars or lines.

How can I quickly identify an outlier on an ACT scatterplot?

An outlier is a data point that sits significantly far away from the general cluster or the line of best fit. On the ACT, outliers are often used to test if you can identify anomalies that don't follow the general trend.
