GRE Geometry Practice Questions Practice Questions with Answers

Concept Explanation

GRE Geometry Practice Questions test your ability to apply fundamental geometric principles including properties of lines, angles, triangles, quadrilaterals, circles, and three-dimensional solids. These questions assess both your knowledge of formulas—such as area, perimeter, and volume—and your ability to reason through complex spatial relationships in a timed environment. Geometry typically accounts for approximately 15% of the Quantitative Reasoning section on the GRE. To succeed, you must be comfortable with the principles of Euclidean geometry and coordinate geometry. While the test provides some basic figures, they are not always drawn to scale unless specifically stated, making it vital to rely on mathematical properties rather than visual estimation. Effective preparation involves integrating these concepts into a broader GRE Prep strategy that emphasizes logical deduction over rote memorization.

Solved Examples

Reviewing step-by-step solutions is a critical part of improving your performance on GRE Geometry Practice Questions. Below are three examples demonstrating common GRE geometry scenarios.

1. Example 1: Triangles and Angles
   In triangle $ABC$, the measure of angle $A$ is $40^\circ$ and the measure of angle $B$ is $70^\circ$. What is the length of side $BC$ if side $AC$ is 10 units long?
   Solution:
   1. First, find the measure of angle $C$ using the rule that the sum of angles in a triangle is $180^\circ$.
   2. $\text{Angle } C = 180^\circ - (40^\circ + 70^\circ) = 70^\circ$.
   3. Since angles $B$ and $C$ are both $70^\circ$, triangle $ABC$ is an isosceles triangle.
   4. In an isosceles triangle, the sides opposite equal angles are equal. Therefore, side $AB = AC$.
   5. Side $BC$ is opposite the $40^\circ$ angle. However, since the question asks for $BC$, and we know the triangle is isosceles with base $BC$, the sides $AB$ and $AC$ are the equal legs. Thus, $AB = 10$. The problem specifically asks for $BC$. In this case, without more info, we use the Law of Sines if needed, but for GRE, usually, it's about identifying the isosceles nature. If $AC = AB = 10$, then $BC$ is simply the base.
2. Example 2: Circle Properties
   A circle is inscribed in a square with a side length of 8. What is the area of the circle?
   Solution:
   1. Identify the relationship between the square and the circle. The diameter of the inscribed circle is equal to the side length of the square.
   2. Diameter $d = 8$.
   3. Calculate the radius: $r = \frac{d}{2} = 4$.
   4. Use the area formula: $\text{Area} = \pi r^2$.
   5. Substitute the radius: $\text{Area} = \pi (4)^2 = 16\pi$.
3. Example 3: Coordinate Geometry
   What is the distance between points $(2, -3)$ and $(5, 1)$ in the Cartesian plane?
   Solution:
   1. Apply the distance formula: $D = \sqrt{(x_2 - x_1)^2 + (y_2 - y_1)^2}$.
   2. Substitute the coordinates: $D = \sqrt{(5 - 2)^2 + (1 - (-3))^2}$.
   3. Simplify the terms: $D = \sqrt{(3)^2 + (4)^2}$.
   4. Calculate the squares: $D = \sqrt{9 + 16} = \sqrt{25}$.
   5. The distance is 5.

Practice Questions

1. A rectangular rug has an area of 60 square feet and a perimeter of 32 feet. What are the dimensions of the rug?
2. In a right triangle, the hypotenuse is 13 and one leg is 5. What is the area of the triangle?
3. If the radius of a cylinder is doubled and its height is halved, by what factor does the volume change?

4. Two lines intersect such that one of the angles formed is $3x - 10$ and the adjacent angle is $2x + 40$. Find the value of $x$.
5. The ratio of the interior angles of a pentagon is $2:3:3:4:6$. What is the measure of the largest angle?
6. A circle has a circumference of $10\pi$. What is the area of a square whose side is equal to the radius of this circle?
7. A cube has a surface area of 150 square centimeters. What is the volume of the cube?
8. In the coordinate plane, line $L$ passes through $(0, 0)$ and $(4, 8)$. What is the equation of a line perpendicular to $L$ that passes through $(2, 1)$?
9. The diagonal of a square is $6\sqrt{2}$. If this square is the base of a cube, what is the total surface area of the cube?
10. Find the length of an arc that subtends a central angle of $60^\circ$ in a circle with a radius of 9.

Answers & Explanations

1. Answer: 6 ft by 10 ft. Let length be $L$ and width be $W$. $L \times W = 60$ and $2(L + W) = 32$, so $L + W = 16$. The numbers that add to 16 and multiply to 60 are 6 and 10.
2. Answer: 30. Use the Pythagorean theorem to find the second leg: $5^2 + b^2 = 13^2 \rightarrow 25 + b^2 = 169 \rightarrow b^2 = 144 \rightarrow b = 12$. Area $= \frac{1}{2} \times \text{base} \times \text{height} = \frac{1}{2} \times 5 \times 12 = 30$.
3. Answer: It doubles (factor of 2). Volume $V = \pi r^2 h$. New volume $V' = \pi (2r)^2 (\frac{h}{2}) = \pi (4r^2) (\frac{h}{2}) = 2\pi r^2 h = 2V$.
4. Answer: 30. Adjacent angles on intersecting lines are supplementary. $(3x - 10) + (2x + 40) = 180 \rightarrow 5x + 30 = 180 \rightarrow 5x = 150 \rightarrow x = 30$.
5. Answer: $180^\circ$. Sum of interior angles of a pentagon $= (5-2) \times 180 = 540$. Total parts $= 2+3+3+4+6 = 18$. One part $= \frac{540}{18} = 30$. Largest angle $= 6 \times 30 = 180^\circ$.
6. Answer: 25. Circumference $2\pi r = 10\pi \rightarrow r = 5$. Side of square $s = 5$. Area of square $= s^2 = 25$.
7. Answer: 125. Surface area of a cube $= 6s^2 = 150$. $s^2 = 25 \rightarrow s = 5$. Volume $= s^3 = 5^3 = 125$.
8. Answer: $y = -\frac{1}{2}x + 2$. Slope of $L = \frac{8-0}{4-0} = 2$. Perpendicular slope $= -\frac{1}{2}$. Equation: $y - 1 = -\frac{1}{2}(x - 2) \rightarrow y = -\frac{1}{2}x + 1 + 1 \rightarrow y = -\frac{1}{2}x + 2$.
9. Answer: 216. Diagonal $d = s\sqrt{2} = 6\sqrt{2} \rightarrow s = 6$. Surface area of cube $= 6s^2 = 6(6^2) = 6 \times 36 = 216$.
10. Answer: $3\pi$. Arc length $= \frac{ heta}{360} \times 2\pi r = \frac{60}{360} \times 2\pi(9) = \frac{1}{6} \times 18\pi = 3\pi$.

1. What is the sum of the exterior angles of any convex polygon?

• A180 degrees
• B270 degrees
• C360 degrees
• D540 degrees

Frequently Asked Questions

How much geometry is on the GRE?

Geometry makes up roughly 15% of the GRE Quantitative section, appearing in various formats like Multiple Choice and Quantitative Comparison. It is important to master these concepts alongside other topics using an AI Exam Simulator to mirror test conditions.

Are geometry formulas provided on the GRE?

No, the GRE does not provide a formula sheet, so you must memorize essential formulas for area, volume, and the Pythagorean theorem. Many students use an AI Flashcard Generator to help commit these geometric properties to memory.

Can I trust the diagrams in GRE geometry questions?

Most diagrams are not drawn to scale unless specifically noted, so you should never rely on visual estimation alone. Always use the provided mathematical data and geometric rules to solve for unknown values.

What are the most common geometry topics tested?

Triangles (especially right and isosceles), circles, and coordinate geometry are the most frequently tested topics. You should also be familiar with the properties of parallel lines and basic three-dimensional solids like cubes and cylinders.

How can I improve my speed on geometry questions?

Speed improves with pattern recognition, such as identifying Pythagorean triples (3-4-5, 5-12-13) and special right triangles. To build this fluency, you can use a Retrieval Challenge to practice recalling these facts under time pressure.
